Bi-directional: To specify that your data be considered bi-directional in nature, insert a check in the Bi-directional check-box.To the right, enter the amount in degrees clockwise from North (0 to 360) by which each lineation measurement should be rotated. Rotate: Insert a check in this box to turn on data rotation.As above, bearings must be entered in degrees (0 - 360) rather than quadrant. Minimum: Enter the minimum lineation or fracture bearing that is to be included in the processing.Azimuth Filter #2: Check this to activate a second bearing filter.

If the data are bi-directional in nature, the program will also filter out the data that is 180 degrees opposite the filter specifications. The maximum azimuth must be designated in a clockwise manner from the minimum.

Maximum: Enter the maximum acceptable lineation bearing.

For this filter, bearings must be entered in degrees (0 - 360) rather than quadrant.

Azimuth Filter #1: Check this to activate a bearing filter.

Any lineations longer than this will be omitted from the diagram and computations. To the right, type in the maximum acceptable length in your map units.

Maximum Length Filter: Check this box to activate an upper length filter.

Any lineations shorter than this will be omitted from the diagram and computations. To the right, type in the minimum acceptable length, in your input units.

Minimum Length Filter: Insert a check here to activate a lower length filter for the lineations.

Length as a Percent of Total Lineation Lengths: This option sets the petal length to represent the percent of total lineation lengths that fall within this bin.
